HYEH15SA滑块、HYEH15CA滑块、HYEH20SA滑块、HYEH20CA滑块、HYEH25SA滑块、HYEH25CA滑块、HYEH30SA滑块、HYEH30CA滑块、HYEH15SA导轨滑块、HYEH15CA导轨滑块、HYEH20SA导轨滑块、HYEH20CA导轨滑块、HYEH25SA导轨滑块、HYEH25CA导轨滑块
发布时间：2025-06-19
导轨型号 |
组件尺寸（mm） |
滑块尺寸（mm） |
滑块重量 | |||||||||||||
|
H |
H1 |
N |
W |
B |
B1 |
C |
L1 |
L |
K1 |
G |
M |
T |
H2 |
H3 | ||
|
HYEH15SA |
24 |
4.5 |
9.5 |
34 |
26 |
4 |
- |
23.1 |
40.1 |
14.8 |
5.7 |
M4*6 |
6 |
5.5 |
6 |
0.09 |
|
HYEH15CA |
26 |
39.8 |
56.8 |
10.15 |
0.15 | |||||||||||
|
HYEH20SA |
28 |
6 |
11 |
42 |
32 |
5 |
- |
29 |
50 |
18.75 |
12 |
M5*7 |
7.5 |
6 |
6 |
0.15 |
|
HYEH20CA |
32 |
48.1 |
69.1 |
12.3 |
0.24 | |||||||||||
|
HYEH25SA |
33 |
7 |
12.5 |
48 |
35 |
6.5 |
- |
35.5 |
59.1 |
21.9 |
12 |
M6*9 |
8 |
8 |
8 |
0.25 |
|
HYEH25CA |
35 |
59 |
82.6 |
16.15 |
0.41 | |||||||||||
|
HYEH30SA |
42 |
10 |
16 |
60 |
40 |
10 |
- |
41.5 |
69.5 |
26.75 |
12 |
M8*12 |
9 |
8 |
9 |
0.45 |
|
HYEH30CA |
40 |
70.1 |
98.1 |
21.05 |
0.76 | |||||||||||
导轨型号 |
导轨尺寸(mm) |
导轨的固定螺栓尺寸(mm) |
基本动额定负荷C(KN) |
基本静额定负荷C0(KN) |
容许静力矩 |
导轨重量 | ||||||||
|
WR |
HR |
D |
h |
d |
P |
E |
MR |
MP |
MY | |||||
|
HYEH15SA |
15 |
12.5 |
6 |
4.5 |
3.5 |
60 |
20 |
M3*16 |
5.35 |
9.40 |
0.08 |
0.04 |
0.04 |
1.25 |
|
HYEH15CA |
7.83 |
16.19 |
0.13 |
0.10 |
0.10 | |||||||||
|
HYEH20SA |
20 |
15.5 |
9.5 |
8.5 |
6 |
60 |
20 |
M5*16 |
7.23 |
12.74 |
0.13 |
0.06 |
0.06 |
2.08 |
|
HYEH20CA |
10.31 |
21.13 |
0.22 |
0.16 |
0.16 | |||||||||
|
HYEH25SA |
23 |
18 |
11 |
9 |
7 |
60 |
20 |
M6*20 |
11.40 |
19.50 |
0.23 |
0.12 |
0.12 |
2.67 |
|
HYEH25CA |
16.27 |
32.40 |
0.38 |
0.32 |
0.32 | |||||||||
|
HYEH30SA |
28 |
23 |
11 |
9 |
7 |
80 |
20 |
M6*25 |
16.42 |
28.10 |
0.40 |
0.21 |
0.21 |
4.35 |
|
HYEH30CA |
23.70 |
47.46 |
0.68 |
0.55 |
0.55 | |||||||||
