搜轴承 -- 黑板报 -- R32-32K2-FSC-2780-2976-0.018滚珠丝杠、R16-16K2-FSC-234-321-0.01...
R32-32K2-FSC-2780-2976-0.018滚珠丝杠、R16-16K2-FSC-234-321-0.018滚珠丝杠、R16-16K2-FSC-284-371-0.018滚珠丝杠、R16-16K2-FSC-334-421-0.018滚珠丝杠、R16-16K2-FSC-384-471-0.018滚珠丝杠、R16-16K2-FSC-434-521-0.018滚珠丝杠、R16-16K2-FSC-484-571-0.018滚珠丝杠
发布时间：2025-05-04
| 規格 | 螺桿外徑 (mm) | 螺帽外徑 (mm) | 螺帽長度 (mm) | 行程 (mm) | L3 (mm) | 動負荷 (kgf) | 靜負荷 (kgf) |
| R16-16K2-FSC-1084-1171-0.018 | 16 | 34 | 47 | 1000 | 1171 | 420 | 690 |
| R16-16K2-FSC-184-271-0.018 | 16 | 34 | 47 | 100 | 271 | 420 | 690 |
| R16-16K2-FSC-234-321-0.018 | 16 | 34 | 47 | 150 | 321 | 420 | 690 |
| R16-16K2-FSC-284-371-0.018 | 16 | 34 | 47 | 200 | 371 | 420 | 690 |
| R16-16K2-FSC-334-421-0.018 | 16 | 34 | 47 | 250 | 421 | 420 | 690 |
| R16-16K2-FSC-384-471-0.018 | 16 | 34 | 47 | 300 | 471 | 420 | 690 |
| R16-16K2-FSC-434-521-0.018 | 16 | 34 | 47 | 350 | 521 | 420 | 690 |
| R16-16K2-FSC-484-571-0.018 | 16 | 34 | 47 | 400 | 571 | 420 | 690 |
| R16-16K2-FSC-534-621-0.018 | 16 | 34 | 47 | 450 | 621 | 420 | 690 |
| R16-16K2-FSC-584-671-0.018 | 16 | 34 | 47 | 500 | 671 | 420 | 690 |
| R16-16K2-FSC-634-721-0.018 | 16 | 34 | 47 | 550 | 721 | 420 | 690 |
| R16-16K2-FSC-684-771-0.018 | 16 | 34 | 47 | 600 | 771 | 420 | 690 |
| R16-16K2-FSC-784-871-0.018 | 16 | 34 | 47 | 700 | 871 | 420 | 690 |
| R16-16K2-FSC-884-971-0.018 | 16 | 34 | 47 | 800 | 971 | 420 | 690 |
| R25-20K3-FSC-1150-1313-0.018 | 25 | 44 | 80 | 1000 | 1313 | 790 | 1715 |
| R25-20K3-FSC-1350-1513-0.018 | 25 | 44 | 80 | 1200 | 1513 | 790 | 1715 |
| R25-20K3-FSC-1550-1713-0.018 | 25 | 44 | 80 | 1400 | 1713 | 790 | 1715 |
| R25-20K3-FSC-1750-1913-0.018 | 25 | 44 | 80 | 1600 | 1913 | 790 | 1715 |
| R25-20K3-FSC-2150-2313-0.018 | 25 | 44 | 80 | 2000 | 2313 | 790 | 1715 |
| R25-20K3-FSC-750-913-0.018 | 25 | 44 | 80 | 600 | 913 | 790 | 1715 |
| R25-20K3-FSC-950-1113-0.018 | 25 | 44 | 80 | 800 | 1113 | 790 | 1715 |
| R25-25K2-FSC-1150-1313-0.018 | 25 | 44 | 69 | 1000 | 1313 | 520 | 1085 |
| R25-25K2-FSC-1350-1513-0.018 | 25 | 44 | 69 | 1200 | 1513 | 520 | 1085 |
| R25-25K2-FSC-1550-1713-0.018 | 25 | 44 | 69 | 1400 | 1713 | 520 | 1085 |
| R25-25K2-FSC-1750-1913-0.018 | 25 | 44 | 69 | 1600 | 1913 | 520 | 1085 |
| R25-25K2-FSC-2150-2313-0.018 | 25 | 44 | 69 | 2000 | 2313 | 520 | 1085 |
| R25-25K2-FSC-750-913-0.018 | 25 | 44 | 69 | 600 | 913 | 520 | 1085 |
| R25-25K2-FSC-950-1113-0.018 | 25 | 44 | 69 | 800 | 1113 | 520 | 1085 |
| R32-25K3-FSC-1180-1376-0.018 | 32 | 54 | 97 | 1000 | 1376 | 1980 | 4410 |
| R32-25K3-FSC-1680-1876-0.018 | 32 | 54 | 97 | 1500 | 1876 | 1980 | 4410 |
| R32-25K3-FSC-2180-2376-0.018 | 32 | 54 | 97 | 2000 | 2376 | 1980 | 4410 |
| R32-25K3-FSC-2780-2976-0.018 | 32 | 54 | 97 | 2600 | 2976 | 1980 | 4410 |
| R32-32K2-FSC-1180-1376-0.018 | 32 | 51 | 87 | 1000 | 1376 | 800 | 1765 |
| R32-32K2-FSC-1680-1876-0.018 | 32 | 51 | 87 | 1500 | 1876 | 800 | 1765 |
| R32-32K2-FSC-2180-2376-0.018 | 32 | 51 | 87 | 2000 | 2376 | 800 | 1765 |
| R32-32K2-FSC-2780-2976-0.018 | 32 | 51 | 87 | 2600 | 2976 | 800 | 1765 |
