HGW15CA滑块|HIWIN滑块轴承、HGW20CA滑块|HIWIN滑块轴承、HGW20HA滑块|HIWIN滑块轴承、HGW25CA滑块|HIWIN滑块轴承、HGW25HA滑块|HIWIN滑块轴承

发布时间：2025-06-20


型号
组件尺寸
(mm)
滑块尺寸
(mm)
滑轨尺寸
(mm)
H
H1
N
W
B
B1
C
L1
L
G
M
T
T1
H2
H3
WR
HR
D
h
d
P
E
HGW 15CA
24
4.3
16
47
38
4.5
30
39.4
61.4
5.3
M5
6
8.9
4.5
5.5
15
15
7.5
5.3
4.5
60
20
HGW 20CA
30
4.6
21.5
63
53
5
40
50.5
77.5
12
M6
8
10
6
7
20
17.5
9.5
8.5
6
60
20
HGW 20HA
65.2
92.2
HGW 25CA
36
5.5
23.5
70
57
6.5
45
58
84
12
M8
8
14
6
9
23
22
11
9
7
60
20
HGW 25HA
78.6
104.6
HGW 30CA
42
6
31
90
72
9
52
70
97.4
12
M10
8.5
16
6.5
10.8
28
26
14
12
9
80
20
HGW 30HA
93
120.4
HGW 35CA
48
7.5
33
100
82
9
62
82
112.4
12
M10
10.1
18
9
12.6
34
29
14
12
9
80
20
HGW 35HA
105.8
138.2
HGW 45CA
60
9.5
37.5
120
100
10
80
97
139.4
12.9
M12
15.1
22
8.5
20.5
45
38
20
17
14
105
22.5
HGW 45HA
128.8
171.2
HGW 55CA
70
13
43.5
140
116
12
95
117.7
166.7
12.9
M14
17.5
26.5
12
19
53
44
23
20
16
120
30
HGW 55HA
155.8
204.8
HGW 65CA
90
15
53.5
170
142
14
110
144.2
200.2
12.9
M16
25
37.5
15
15
63
53
26
22
18
150
35
HGW 65HA
203.6
259.6

型号

滑轨的
固定螺栓尺寸
(mm)

基本动
额定负荷
C(kN)
基本静
额定负荷
C0(kN)
容许静力矩
重量
MR
(kN-m)
MP
(kN-m)
MY
(kN-m))
滑块
(kg)
滑轨
(kg/m)
HGW 15CA
M4×16
11.38
25.31
0.17
0.15
0.15
0.17
1.45
HGW 20CA
M5×16
17.75
37.84
0.38
0.27
0.27
0.40
2.21
HGW 20HA
21.18
48.84
0.48
0.47
0.47
0.52
HGW 25CA
M6×20
26.48
56.19
0.64
0.51
0.51
0.59
3.21
HGW 25HA
32.75
76.00
0.87
0.88
0.88
0.80
HGW 30CA
M8×25
38.74
83.06
1.06
0.85
0.85
1.09
4.47
HGW 30HA
47.27
110.13
1.40
1.47
1.47
1.44
HGW 35CA
M8×25
49.52
102.87
1.73
1.20
1.20
1.56
6.30
HGW 35HA
60.21
136.31
2.29
2.08
2.08
2.06
HGW 45CA
M12×35
77.57
155.93
3.01
2.35
2.35
2.79
10.41
HGW 45HA
94.54
207.12
4.00
4.07
4.07
3.69
HGW 55CA
M14×45
114.44
227.81
5.66
4.06
4.06
4.52
15.08
HGW 55HA
139.35
301.26
7.49
7.01
7.01
5.96
HGW 65CA
M16×50
163.63
324.71
10.02
6.44
6.44
9.17
21.18
HGW 65HA
208.36
457.15
14.15
11.12
11.12
12.89
