Tr28x10梯形丝杆、Tr30x3梯形丝杆、Tr30x6梯形丝杆、Tr32x12梯形丝杆、Tr32x3梯形丝杆、Tr32x5梯形丝杆、Tr32x6梯形丝杆、Tr32x12梯形丝杆、Tr36x6梯形丝杆、Tr36x12梯形丝杆、Tr40x7梯形丝杆、Tr40x14梯形丝杆、Tr44x7梯形丝杆、Tr44x12梯形丝杆、Tr44x14梯形丝杆、Tr50x8梯形丝杆、Tr50x12梯形丝杆、Tr55x9梯形丝杆、Tr55x14梯形丝杆

发布时间：2025-06-20

梯形丝杆型号订货电话18920813261

代码螺距 (mm) d (mm) d2 (mm) d3 (mm) 螺距误差 (mm/300mm) 直线度 (mm/300mm)

大小大小大小

Tr18x2梯形丝杆 2 18 17.82 16.93 16.73 15.5 15.12 0.1 0.3

Tr18x4梯形丝杆 4 17.7 15.91 15.64 13.5 12.47 0.1 0.3

Tr18x8梯形丝杆 4 17.43 15.91 15.61 13.5 12.47 0.2 0.3

Tr20x2梯形丝杆 2 20 19.82 18.93 18.73 17.5 17.18 0.1 0.3

Tr20x4梯形丝杆 4 19.7 17.91 17.64 15.5 14.47 0.1 0.3

Tr20x8梯形丝杆 4 19.7 17.9 17.61 15.5 14.47 0.2 0.3

Tr22x3梯形丝杆 3 22 21.76 20.41 20.19 18.5 18.14 0.1 0.2

Tr22x5梯形丝杆 5 21.66 19.39 19.11 16.5 15.29 0.1 0.2

Tr22x8梯形丝杆 4 21.7 19.9 19.61 17.5 16.47 0.2 0.2

Tr22x10梯形丝杆 5 21.66 19.39 19.08 16.5 15.29 0.2 0.2

Tr24x3梯形丝杆 3 24 23.76 22.41 22.17 20.5 20.14 0.1 0.2

Tr24x5梯形丝杆 5 23.66 21.39 21.09 18.5 17.27 0.1 0.2

Tr24x10梯形丝杆 5 23.66 21.39 21.06 18.5 17.27 0.2 0.2

Tr26x3梯形丝杆 3 26 25.76 24.41 24.17 22.5 20.14 0.1 0.2

Tr26x5梯形丝杆 5 25.67 23.39 23.09 20.5 19.27 0.1 0.2

Tr26x8梯形丝杆 4 25.5 21.87 21.49 17 16.4 0.1 0.2

Tr26x10梯形丝杆 5 25.67 23.39 23.09 20.5 19.27 0.2 0.2

Tr28x3梯形丝杆 5 28 27.76 26.41 26.17 24.5 24.1 0.1 0.2

Tr28x5梯形丝杆 5 27.67 25.39 25.09 22.5 21.27 0.1 0.2

Tr28x10梯形丝杆 5 27.67 25.39 25.06 22.5 21.27 0.2 0.2

Tr30x3梯形丝杆 3 30 29.76 28.41 28.17 26.5 26.4 0.1 0.2

Tr30x6梯形丝杆 6 29.63 26.88 26.55 23 21.56 0.2 0.2

Tr32x12梯形丝杆 6 29.63 26.88 26.51 23 21.56 0.1 0.2

Tr32x3梯形丝杆 3 32 31.76 30.5 30.25 28.5 28.1 0.1 0.2

Tr32x5梯形丝杆 5 31.67 29.39 29.09 26.5 25.27 0.1 0.2

Tr32x6梯形丝杆 6 31.63 28.88 28.55 25 23.56 0.1 0.2

Tr32x12梯形丝杆 6 31.63 28.88 28.51 25 23.56 0.2 0.2

Tr36x6梯形丝杆 6 36 35.63 32.88 32.55 29 27.56 0.1 0.2

Tr36x12梯形丝杆 6 35.63 32.88 32.51 29 27.56 0.2 0.2

Tr40x7梯形丝杆 7 40 39.58 36.38 36.02 32 30.38 0.1 0.2

Tr40x14梯形丝杆 7 39.58 36.38 35.98 32 30.38 0.2 0.2

Tr44x7梯形丝杆 7 44 43.57 40.37 40.02 36 34.38 0.1 0.2

Tr44x12梯形丝杆 12 43.4 37.84 37.42 31 30.18 0.1 0.2

Tr44x14梯形丝杆 7 43.57 40.37 39.98 36 34.38 0.2 0.2

Tr50x8梯形丝杆 8 50 49.55 45.87 45.47 41 39.17 0.1 0.2

Tr50x12梯形丝杆 12 49.4 43.84 43.37 37 36.25 0.1 0.2

Tr55x9梯形丝杆 9 55 54.5 55.36 49.94 45 42.98 0.1 0.2

Tr55x14梯形丝杆 14 54.33 47.82 47.32 39 38.2 0.1 0.2

Tr60x9梯形丝杆 9 60 59.5 55.36 54.94 50 47.98 0.1 0.2

Tr60x14梯形丝杆 14 59.33 52.82 52.32 44 43.2 0.1 0.2

Tr70x10梯形丝杆 10 70 69.47 64.85 64.43 59 56.82 0.1 0.4

Tr70x16梯形丝杆 16 69.29 61.81 61.28 52 51.15 0.1 0.4

Tr80x10梯形丝杆 10 80 79.47 74.85 74.43 69 66.82 0.1 0.4

Tr80x16梯形丝杆 16 79.29 71.81 71.28 62 61.15 0.1 0.4

Tr90x12梯形丝杆 12 90 89.4 83.84 83.37 77 74.45 0.1 0.5

Tr90x18梯形丝杆 18 89.2 80.8 80.24 70 69.1 0.1 0.5

Tr95x12梯形丝杆 12 95 94.4 88.84 88.34 82 81.22 0.1 0.5

Tr95x16梯形丝杆 16 94.3 88.84 86.25 77 73.71 0.1 1

Tr95x18梯形丝杆 18 94.2 85.8 85.2 75 74.05 0.1 1

Tr100x12梯形丝杆 12 100 99.4 93.84 93.34 87 86.22 0.1 1

Tr100x16梯形丝杆 16 99.29 91.81 91.25 82 78.71 0.1 1

Tr100x20梯形丝杆 20 99.15 89.79 89.19 78 77.01 0.1 1

Tr120x14梯形丝杆 14 120 119.33 112.82 112.29 104 103.16 0.1 1

Tr120x16梯形丝杆 16 119.29 111.81 111.25 102 98.71 0.1 1

Tr120x22梯形丝杆 22 119.1 108.78 108.15 96 94.99 0.1 1
