英制圆锥滚子轴承
发布时间：2025-05-05
 |
|
Bearing No. |
d×D×T(mm) |
Mass(kg) |
Bearing No. |
d×D×T(mm) |
Mass(kg) |
|
5BC |
28.313 |
0.0154 |
15113/15245 |
28.575×62×19.05 |
0.28 |
|
11BC |
33.297 |
0.0275 |
16137/16282 |
34.925×72×19 |
0.36 |
|
09067/09195 |
19.05×49.225×18.034 |
0.1804 |
16150/16282 |
38.1×72×19 |
0.332 |
|
09081/09195 |
20.625×49.225×19.845 |
0.1555 |
1755/1729 |
22.225×56.896×19.368 |
0.254 |
|
TR101204/72487 |
50×123.825×36.512 |
2.101 |
17887/17831 |
45.23×79.985×19.842 |
0.41 |
|
LM104949/LM104911 |
50.8×82.55×21.59 |
0.42 |
18590/18520 |
41.275×73.025×16.667 |
0.285 |
|
JLM104947A/JLM104910 |
50×82×21.976 |
0.434 |
18790/18720 |
50.800×85×17.462 |
0.42 |
|
JLM104948/JLM104910 |
50×82×21.5 |
0.422 |
HM21207/HM212011 |
63.5×122.238×38.1 |
1.84 |
|
LM104949/JLM104910 |
50.8×82×21.976 |
0.418 |
HM212049/HM212011 |
66.675×122.238×38.1 |
1.85 |
|
LM104949E/LM104911 |
50.8×82.55×16.51 |
0.438 |
HM218248/HM218210 |
89.974×146.975×40 |
2.52 |
|
JLM104948/LM104911 |
50×82.55×21.115 |
0.424 |
24780/24720 |
41.275×76.2×22.225 |
0.424 |
|
LM104949/LM104912 |
50.8×82.931×21.59 |
0.425 |
25570/25520 |
36.513×82.931×23.813 |
0.651 |
|
LM102949/LM102910 |
45.252×73.431×19.558 |
0.303 |
25572/25520 |
38.1×82.931×23.813 |
0.642 |
|
11590/11520 |
15.875×42.862×14.288 |
1.001 |
25577/25520 |
42.875×82.931×23.812 |
0.69 |
|
LM11749/LM11710 |
17.462×39.878×13.843 |
0.083 |
25577/25522 |
42.875×83.058×23.876 |
0.70 |
|
LM11949/LM11910 |
19.05×45.237×15.494 |
0.124 |
25580/25520 |
44.45×82.931×23.812 |
0.561 |
|
M12649/M12610 |
21.43×50.005×17.526 |
0.174 |
25581/25520 |
44.45×82.931×23.812 |
0.563 |
|
LM12748/LM12710 |
21.43×45.237×15.494 |
0.118 |
25590/25520 |
45.618×82.931×23.812 |
0.54 |
|
LM12749/LM12710 |
22×45.237×15.494 |
0.116 |
25590/25521 |
45.618×83.058×23.812 |
0.534 |
|
LM12749/LM12711 |
22×46×15.494 |
0.121 |
25590/25522 |
45.618×83.058×23.876 |
0.538 |
|
13686/13620 |
38.1×69.012×19.05 |
0.296 |
25590/25523 |
45.618×82.931×26.988 |
0.584 |
|
14125A/14276 |
31.75×69.012×19.845 |
0.349 |
25877/25820 |
34.925×73.025×23.812 |
0.474 |
|
14137A/14276 |
34.925×69.012×19.845 |
0.325 |
25877/25821 |
34.925×73.025×23.812 |
0.468 |
|
14138A/14276 |
34.925×69.012×19.845 |
0.322 |
25880/25821 |
36.487×73.025×23.812 |
0.451 |
|
14138/14274 |
34.925×69.012×19.845 |
0.32 |
27687/27620 |
82.55×125.412×25.4 |
1.50 |
|
15101/15245 |
25.4×62×19.05 |
0.2821 |
2785/2720 |
33.338×76.2×23.813 |
0.544 |
|
15123/15245 |
31.75×62×19.05 |
0.2331 |
2788/2729 |
38.1×76.2×23.813 |
0.496 |
|
15123/15243 |
31.75×61.912×19.05 |
0.2301 |
2788/2720 |
38.1×76.2×23.813 |
0.49 |
|
15103S/15245 |
26.162×62×19.05 |
0.2791 |
2790/2720 |
33.338×76.2×23.813 |
0.549 |
|
15126/15245 |
31.75×62×19.05 |
0.255 |
2790/2729 |
33.338×76.2×23.813 |
0.555 |
|
28580/28521 |
50.8×92.075×24.608 |
0.697 |
462/453X |
57.15×104.775×30.162 |
1.08 |
|
28584/28521 |
52.388×92.075×24.608 |
0.669 |
L44643/L44610 |
25.4×50.292×14.224 |
0.129 |
|
28678/28622B |
50.8×97.63×24.608 |
0.865 |
L44643L/L44610 |
25.4×50.292×14.224 |
0.129 |
|
28985/28920 |
60.325×101.6×25.4 |
0.79 |
L44649/L44610 |
26.988×50.292×14.224 |
0.124 |
|
29590/29522 |
66.675×107.95×25.4 |
0.874 |
L45449/L45410 |
29×50.292×14.224 |
0.113 |
|
29685/29620 |
73.025×112.712×25.4 |
0.861 |
LM48548/LM48510 |
34.92×65.088×18.034 |
0.2584 |
|
LM29749/LM29710 |
38.1×65.088×18.034 |
0.238 |
LM501349/LM501310 |
41.275×73.431×19.558 |
0.333 |
|
LM300849/LM300811 |
41×68×17.5 |
0.2403 |
LM501349/LM501314 |
41.275×73.431×21.43 |
0.353 |
|
JLM506849/10 |
55×90×23 |
0.69 |
HM518445/HM518410 |
88.9×152.4×39.688 |
2.875 |
|
57414/LM300811 |
41×68×17.5 |
0.2433 |
575/572 |
76.2×139.992×36.512 |
2.442 |
|
33275/33462 |
69.85×117.475×30.112 |
1.28 |
593/592A |
88.9×152.4×39.688 |
2.78 |
|
33281/33472 |
71.438×120×29.794 |
1.33 |
LM603049/LM603011 |
45.242×77.788×19.842 |
0.358 |
|
33889/33821 |
50.8×95.25×27.783 |
0.862 |
LM603049/LM603012 |
45.242×77.788×21.43 |
0.377 |
|
3579/3525 |
42.862×87.312×30.162 |
0.805 |
A6075/A6157 |
19.05×39.992×12.014 |
0.066 |
|
368A/362A |
50.8×88.9×20.638 |
0.153 |
L610549/L610510 |
63.5×94.458×19.05 |
0.449 |
|
368/362 |
50.8×90×20 |
0.562 |
LM67048/LM67010 |
31.75×59.131×15.875 |
0.179 |
|
3776/20 |
44.983×93.264×30.162 |
0.73 |
LM67049A/LM67010 |
31.75×59.131×15.875 |
0.184 |
|
3780/3720 |
50.8×93.264×30.162 |
0.856 |
67989/67920 |
209.55×282.575×46.038 |
7.73 |
|
3782/3720 |
44.45×93.264×30.162 |
0.735 |
L68149/L68110 |
34.981×59.131×15.875 |
0.1702 |
|
3872/3820 |
34.925×85.725×30.162 |
0.88 |
L68149/L68111 |
34.981×59.974×15.875 |
0.1770 |
|
387AS/382A |
57.150×96.838×21 |
0.593 |
JL69349/JL69310 |
38×63×17 |
0.196 |
|
387A/382S |
57.15×96.838×25.4 |
0.669 |
JM716649/JM716610 |
85×130×130 |
1.704 |
|
387A/382 |
57.15×98.425×21 |
0.646 |
78215C/78551 |
53.975×140.03×36.512 |
2.7122 |
|
387A/382A |
57.15×96.838×21 |
0.598 |
M802048/M802011 |
41.275×82.55×26.543 |
0.615 |
|
U399/U360L |
39.688×73.025×19.395 |
0.357 |
HM803146/HM803110 |
41.275×88.9×30.162 |
0.886 |
|
3982/3920 |
63.5×112.713×30.162 |
1.22 |
HM803149/HM803110 |
44.450×88.9×30.162 |
0.836 |
|
3984/3920 |
66.675×112.713×30.162 |
1.14 |
JL819349/JL819310 |
95×125×20 |
0.8382 |
|
390A/394A |
63.5×110×22 |
0.851 |
M86649/M86610 |
30.162×64.292×21.433 |
0.337 |
|
42688/42620 |
76.2×127×30.162 |
0.40 |
M88048/M88010 |
33.338×68.262×22.225 |
0.383 |
|
|
|
|
HM88649/HM88610 |
34.925×72.333×25.4 |
0.479 | |
