叁件套内螺纹杆端轴承AF3、AF4、AF5、AF6、AF7、AF8、AF10、AF12、AF14、AF16、AF3L、AF4L、AF5L、AF6L、AF7L、AF8L、AF10L、AF12L、AF14L、AF16L
发布时间：2026-01-30
|
|
| Dimensions in inches |
| 型 号 |
B |
W |
H |
A |
D |
K |
J |
|
C |
M |
a |
Ultimate |
| Radial |
| Part Number |
Ball |
Ball |
Housing |
Centerline |
Head |
Shank |
Wrench |
Ball |
Thread |
Thread |
Misalign |
Static Load |
| Right |
Left |
Bore |
Width |
Width |
Length |
Diameter |
Diameter |
Flat Width |
Diameter |
Length |
Size |
Angle |
Capacity |
| Hand |
Hand |
+0.0015 |
+0.000 |
|
+0.010 |
+0.010 |
+0.010 |
+0.010 |
|
+0.062 |
UNF-3A |
Min |
Lbs |
| |
|
--0.0005 |
--0.005 |
|
--0.010 |
--0.010 |
--0.010 |
--0.010 |
|
--0.031 |
| AF3( T ) |
AF3L( T ) |
0.1900 |
0.312 |
0.250 |
1.062 |
0.625 |
0.406 |
0.312 |
0.437 |
0.562 |
10-32 |
13 |
3733 |
| AF4( T ) |
AF4L( T ) |
0.2500 |
0.375 |
0.281 |
1.312 |
0.750 |
0.469 |
0.375 |
0.500 |
0.750 |
1/4-28 |
16 |
6190 |
| AF5( T ) |
AF5L( T ) |
0.3125 |
0.437 |
0.344 |
1.375 |
0.875 |
0.500 |
0.437 |
0.625 |
0.750 |
5/16-24 |
14 |
7639 |
| AF6( T ) |
AF6L( T ) |
0.3750 |
0.500 |
0.406 |
1.625 |
1.000 |
0.687 |
0.562 |
0.719 |
0.937 |
3/8-24 |
12 |
9544 |
| AF7( T ) |
AF7L( T ) |
0.4375 |
0.562 |
0.437 |
1.812 |
1.125 |
0.750 |
0.625 |
0.812 |
1.062 |
7/16-20 |
14 |
10285 |
| AF8( T ) |
AF8L( T ) |
0.5000 |
0.625 |
0.500 |
2.125 |
1.312 |
0.875 |
0.750 |
0.937 |
1.187 |
1/2-20 |
12 |
16238 |
| AF10( T ) |
AF10L( T ) |
0.6250 |
0.750 |
0.562 |
2.500 |
1.500 |
1.000 |
0.875 |
1.125 |
1.500 |
5/8-18 |
16 |
17955 |
| AF12( T ) |
AF12L( T ) |
0.7500 |
0.875 |
0.687 |
2.875 |
1.750 |
1.125 |
1.000 |
1.312 |
1.750 |
3/4-16 |
14 |
28081 |
| AF14( T ) |
AF14L( T ) |
0.8750 |
0.875 |
0.765 |
3.375 |
2.000 |
1.300 |
1.125 |
1.375 |
1.875 |
7/8-14 |
17 |
45051 |
| AF16( T ) |
AF16L( T ) |
1.0000 |
1.375 |
1.000 |
4.125 |
2.750 |
1.625 |
1.500 |
1.875 |
2.125 |
1 1/4-12 |
17 |
76200 | | |
