进口WS1113、WS1211、WS81102、WS81103、WS81104、WS81105、WS81106、WS81107、WS81108、WS81109、WS8111、WS81110、WS81112、WS81114、WS81115、WS81116、WS81117、WS81118

发布时间：2025-12-16

型号产地内径外径宽度重量

WS1113 FAG 45 90 5.25 0.124

WS1211 FAG 55 90 7 0.225

WS81102 FAG 15 28 2.75 0.0093

WS81103 FAG 17 30 2.75 0.0102

WS81104 FAG 20 35 2.75 0.0138

WS81105 FAG 25 42 3 0.021

WS81106 FAG 30 47 3 0.024

WS81107 FAG 35 52 3.5 0.0315

WS81108 FAG 40 60 3.5 0.0425

WS81109 FAG 45 65 4 0.0535

WS8111 FAG 55 78 5 0.093

WS81110 FAG 50 70 4 0.0585

WS81112 FAG 60 85 47 0.105

WS81114 FAG 70 95 5.25 0.132

WS81115 FAG 75 100 5.75 0.153

WS81116 FAG 80 105 5.75 0.162

WS81117 FAG 85 110 5.75 0.17

WS81118 FAG 90 120 6.5 0.25

上一篇：外球面轴承带座SBP201-8G、SBP202-10G、SBP203-11G、SBP2G、SBP204-12G、SBP205-14G、SBP205-16G、SBP206-19G、SBP206-18G、SBP206-20G、SBP207-21G、SBP207-22G、SBP207-23G、SBP208-24G、SBP209-26G、SBP209-27G、SBP209-28G、SBP209-30G、SBP210-31G、SBP211-32G、SBP212-36G、SBP212-38G、SBP212-39G —— 下一篇：杆端关节轴承国内外对照表

返回搜轴承首页

型号	产地	内径	外径	宽度	重量
WS1113	FAG	45	90	5.25	0.124
WS1211	FAG	55	90	7	0.225
WS81102	FAG	15	28	2.75	0.0093
WS81103	FAG	17	30	2.75	0.0102
WS81104	FAG	20	35	2.75	0.0138
WS81105	FAG	25	42	3	0.021
WS81106	FAG	30	47	3	0.024
WS81107	FAG	35	52	3.5	0.0315
WS81108	FAG	40	60	3.5	0.0425
WS81109	FAG	45	65	4	0.0535
WS8111	FAG	55	78	5	0.093
WS81110	FAG	50	70	4	0.0585
WS81112	FAG	60	85	47	0.105
WS81114	FAG	70	95	5.25	0.132
WS81115	FAG	75	100	5.75	0.153
WS81116	FAG	80	105	5.75	0.162
WS81117	FAG	85	110	5.75	0.17
WS81118	FAG	90	120	6.5	0.25
