(dimensions in mm)

Bearing Type - Cast iron housing

Dynamic Load Rating (Cr) - 14,022

Static Load Rating (Cor) - 7,843

Shaft Dia. (Fw) - 25.0000

Housing Width (b) - 68.0000

Mounting Hole Center-to-Center (e) - 99.0000

Housing Length (a) - 130.0000

Housing Base Thickness (g) - 13.0000

Bearing Inner Race Width (Bi) - 34.0000

Bearing Inner Race Width - Short Side (n) - 14.0000

Bearing Inner Race Width - Extended Side (m) - 20.0000

Mounting Bolt Size - 10.0000

Housing Number - FL 205E

Mounting Hole Dia. (s) - 12.0000

Flange Assembly Height (Z) - 37.0000

Flange Height (l) - 27.0000

Mounting Base to Bearing Center (i) - 16.0000

Weight (g) - 634.00

Material - Cast iron housing, chrome steel bearing

Also available with eccentric locking collar.

Medium Duty, Heavy Duty and other available types are described in the Bearing Types information.

Various seal options and plated housing options are described in the Nomenclature and Bearing Types information.

• AST UCFL205轴承单元图纸和参数

• 发布时间：2026-09-01
• 产品型号: UCFL205
• 新型号:UCFL 205
• 内径：25mm 外径：mm 厚度：mm
• 主要类别：轴承单元
• 应用行业:轮胎行业,色谱仪,液压连接件,检验化验仪器及配件,动物跟踪,服装加工,塑料成型,播出系统,交通消防设备,工业换气扇电机,水泵行业
• 近似型号:KOYO UCFA205-14 NACHI UKF205+H2305 SNR EXPG205 FYH NAPK205-14 SNR USFAE205 KOYO UCT205-15 KOYO UCF205-16E FYH UCFB205 KOYO SAPP205-15 KOYO SAPFL205
• 天津八零动力国际贸易有限公司专业经销 UCFL 205产品，常年备货AST UCFL 205 轴承单元. 我们可以可以快速将您所需要的UCFL 205产品运送到全球任意地方购买 AST UCFL 205 我认准八零动力工业，价格低，品种全，交货快，质量有保证！ 轴承单元订购电话022-58519723/22/21
