搜轴承 -- SKF轴承型号查询 -- 轴承单元 -- SKF FY 35 FM轴承

d - 35 mm

A - 34.5 mm

A₁ - 13 mm

A₃ - H14 - 3.2 mm

A₅ - 22 mm

B₁ - 38.9 mm

D_a - H11 - 106.4 mm

D_b1 - 87 mm

D_b2 - 95 mm

J - 92 mm

L - 118 mm

H - 14 mm

s₁ - 29.4 mm

T - 50.4 mm

J₆ - 106 mm

J₇ - 29 mm

N₄ - 4 mm

D_N - 6.5 mm

SW_N - 7 mm

G_N - 1/4-28 SAE-LT

R_G - 1/4-28 UNF

R₁ - 22.5 mm

Basic dynamic load rating - C - 25.5 kN

Basic static load rating - C₀ - 15.3 kN

Fatigue load limit - P_u - 0.655 kN

Limiting speed - 5300 r/min

Mass bearing unit - 1.3 kg

Thread - G₂ - M10x1

Hexagonal key size for grub screw - H - 5 mm

Recommended tightening torque for grub screw - 16.5 N·m

• SKF FY35FM轴承单元图纸和参数

• 发布时间：2026-05-02
• 产品型号: FY35FM
• 新型号:FY 35 FM
• 内径：35mm 外径：34,5mm 厚度：13mm
• 主要类别：轴承单元
• 应用行业:环卫设施,激光切割,农业,潜水装备,轴颈车床,动态血压,液体胶类,红外技术,螺纹磨床,通风加温设备,整形设备
• 近似型号:FYH UCTX11-35 INA PCJY35-N FYH UCTX11-35E KOYO UCCX11-35 FYH NAPK211-35 SKF FYNT 35 F NKE PASEY35-N NKE PMEY35-N INA RCJTY35-JIS KOYO UCF211-35
