搜轴承 -- SKF轴承型号查询 -- 轴承单元 -- SKF FYNT 45 L轴承

d_a - 45 mm

A₁ - 66 mm

A₂ - 15 mm

T - max. - 72.5 mm

B - 65 mm

H - 160 mm

H₁ - 60 mm

J - 160 mm

L - 179 mm

D_a - 100 mm

H - 14 mm

a - 5 mm

S - 2.5 mm

J₁ - 71 mm

J₂ - 20 mm

J₃ - 53 mm

J₄ - 45.5 mm

J₅ - 18 mm

J₆ - 72 mm

N₄ - max. - 6 mm

A₃ - 52 mm

A₅ - 23 mm

b_a - min. - 34 mm

b_a - max. - 43 mm

Basic dynamic load rating - C - 102 kN

Basic static load rating - C₀ - 98 kN

Fatigue load limit - P_u - 10.8 kN

Limiting speed - 3500 r/min

Calculation factor - e - 0.26

Calculation factor - Y₁ - 2.6

Calculation factor - Y₂ - 3.9

Diameter - d_m - 65 mm

Basic Designation bearing - 22209 E

P_a - 15 kN

P₁ - 100 kN

P₂ - 65 kN

P₃ - 105 kN

Mass bearing unit - 3.9 kg

Diameter - G - 12 mm

• SKF FYNT45L轴承单元图纸和参数

• 发布时间：2025-05-02
• 产品型号: FYNT45L
• 新型号:FYNT 45 L
• 内径：45mm 外径：66mm 厚度：15mm
• 主要类别：轴承单元
• 应用行业:工业用料,化学原料及试剂,刀架行业,激光器件,一次性类,气缸标准型,台架器具,工程机械,仪器仪表,钢材行业,气爪摆动
• 近似型号:SKF FY 45 FM INA RASEL45 INA RHE45 NKE PSHE45 SKF SY 45 TF/VA201 SKF PF 45 TF SKF SY 45 TF INA PMEY45 NKE PMEY45 SKF FYJ 45 KF+HE 2309
• 天津八零动力国际贸易有限公司专业经销 FYNT 45 L产品，常年备货SKF FYNT 45 L 轴承单元. 我们可以可以快速将您所需要的FYNT 45 L产品运送到全球任意地方购买 SKF FYNT 45 L 我认准八零动力工业，价格低，品种全，交货快，质量有保证！ 轴承单元订购电话022-58519723/22/21
