NA231400/231976CD轴承、HM265049/HM265010D轴承、HM265049TDS/HM265010S轴承、M270749ADW/M270710轴承、EE243196/243251CD轴承、600KBE030+L/P6轴承
发布时间：2025-05-05
|
|
|
基本尺寸 |
基本额定负荷 |
极限转速 |
重量 |
型号 |
|
Principal Dimensions |
Basic Load Ratings |
Limiting Speeds |
Wt |
No. |
|
d |
D |
T |
B |
C |
Cr |
Cor |
Greast |
Oil |
|
|
|
mm |
KN |
r/min |
kg |
|
|
92.075 |
152.4 |
82.55 |
63.5 |
36.322 |
297 |
547 |
1800 |
2400 |
5.74 |
598/592DC |
|
96.938 |
188.912 |
107.59 |
31.75 |
46.038 |
466 |
702 |
1800 |
2400 |
11.6 |
90381/90744K |
|
101.6 |
168.275 |
92075 |
69.85 |
41.275 |
357 |
648 |
1800 |
2400 |
8.18 |
687/672D |
|
101.6 |
190.5 |
127 |
101.6 |
57.5 |
606 |
1020 |
1800 |
2400 |
15.6 |
861/854D |
|
127.792 |
228.6 |
115.888 |
84.138 |
49.428 |
703 |
1142 |
1400 |
1900 |
18.9 |
HM926749
/HM926710D |
|
130 |
280 |
144 |
44 |
66 |
1086 |
1649 |
1400 |
1900 |
40.4 |
31326X.K11
.A160.200 |
|
140 |
200 |
93.665 |
73.025 |
42 |
422 |
917 |
1300 |
1700 |
9.2 |
442210 |
|
|
300 |
154 |
47 |
70 |
1244 |
1910 |
1300 |
1700 |
51 |
31328X.K11
.A160.200 |
|
146.05 |
254 |
149.225 |
111.125 |
66.675 |
967 |
1887 |
1300 |
1700 |
28 |
99575/99102CD |
|
150 |
320 |
164 |
50 |
75 |
1414 |
2196 |
1200 |
1500 |
59.6 |
31330X.K11
.A180.230 |
|
165.1 |
225.425 |
95.25 |
69.85 |
47.625 |
440 |
1120 |
1150 |
1400 |
10.5 |
NA46790-SW
/46720CD |
|
173 |
350 |
155 |
58 |
155 |
1500 |
2550 |
1000 |
1300 |
70.7 |
173KH350+K |
|
177.8 |
288.925 |
123.825 |
47.625 |
123.825 |
1085 |
2050 |
940 |
1300 |
32 |
HM237546DW
/HM237510 |
|
203.2 |
276.225 |
95.25 |
73.025 |
47.625 |
590 |
1350 |
940 |
1300 |
14.9 |
LM241149NW
/LM241110D |
|
|
292.1 |
109.538 |
84.138 |
49.212 |
825 |
1710 |
940 |
1300 |
21.9 |
M541349
/M541310D |
|
220 |
340 |
90 |
80 |
39 000 |
725 |
1478 |
840 |
1100 |
30.8 |
220KBE30+L |
|
249.25 |
38l.000 |
171.45 |
127 |
76.2 |
1407 |
3066 |
690 |
920 |
63.4 |
EE126098
/126151CD |
|
253.975 |
347.662 |
101.6 |
69.85 |
50.8 |
775 |
1650 |
630 |
840 |
23.8 |
LM249747NW
/LM249710D |
|
279.4 |
457.2 |
244.475 |
106.363 |
244475 |
3670 |
8440 |
580 |
770 |
181 |
HH255149D
/HH255110 |
|
|
457.2 |
244.48 |
94 |
244.48 |
2743 |
5863 |
580 |
770 |
166.5 |
45T564624T |
|
303.212 |
495.3 |
263.525 |
114.3 |
263.525 |
4023 |
9363 |
500 |
660 |
223.8 |
HH258249TD
/HH258210 |
|
304.8 |
393.7 |
107.95 |
82.55 |
53.975 |
905 |
2260 |
500 |
660 |
30.6 |
L357049NW
/LM961511D |
|
305.07 |
500 |
200 |
60 |
200 |
2100 |
4300 |
500 |
660 |
147.7 |
332169A |
|
342.9 |
457.098 |
142.875 |
10l.600 |
63.5 |
1254 |
3411 |
480 |
630 |
60.4 |
LM961548
/LM961511D |
|
355.6 |
444.5 |
136.525 |
111.125 |
60.325 |
1133 |
3538 |
420 |
560 |
44.6 |
L163149
/L163110CD |
|
|
501.65 |
146.05 |
107.95 |
73.025 |
1762 |
3853 |
410 |
540 |
88 |
NA231400
/231976CD |
|
368.249 |
523. 875 |
214.312 |
169.862 |
101.6 |
2714 |
6903 |
410 |
540 |
143 |
HM265049
/HM265010D |
|
368.3 |
523. 875 |
185.738 |
79.375 |
185.738 |
3165 |
7555 |
410 |
540 |
134.3 |
HM265049TDS
/HM265010S |
|
447.675 |
635 |
223.838 |
95.25 |
223.838 |
4317 |
11416 |
320 |
440 |
239 |
M270749ADW
/M270710 |
|
498.475 |
634.873 |
177.8 |
142.875 |
80.962 |
2356 |
6893 |
320 |
440 |
132.2 |
EE243196
/243251CD |
|
600 |
870 |
250 |
200 |
111 |
4920 |
11950 |
250 |
330 |
467 |
600KBE030+L
/P6 | |
