搜轴承 -- 黑板报 -- A6067/A6157A单列英制圆锥滚子轴承、A6067/A6157单列英...
A6067/A6157A单列英制圆锥滚子轴承、A6067/A6157单列英制圆锥滚子轴承、05066/05185单列英制圆锥滚子轴承、A5069/A5144单列英制圆锥滚子轴承、LM11749/LM11710单列英制圆锥滚子轴承、4C/6单列英制圆锥滚子轴承、05068/05175单列英制圆锥滚子轴承、05070XS/05185-S单列英制圆锥滚子轴承、05070X/05185-S单列英制圆锥滚子轴承
发布时间：2025-05-04
| 轴承型号 | 轴承尺寸 | 额定载荷 | |||||||||
| 动载 | 系数 | 动载 | 系数 | 静载 | |||||||
| 内圈 | 外圈 | d | D | T | C1 | e | Y | C90 | Ca90 | K | C0 |
| A2031 | A2126 | 7.938 | 31.991 | 10.008 | 10600 | 0.41 | 1.48 | 2750 | 1910 | 1.44 | 9230 |
| A2037 | A2126 | 9.525 | 31.991 | 10.008 | 10600 | 0.41 | 1.48 | 2750 | 1910 | 1.44 | 9230 |
| A4044 | A4138 | 11.112 | 34.988 | 10.998 | 12200 | 0.45 | 1.32 | 3160 | 2450 | 1.29 | 11500 |
| A2047 | A2126 | 11.987 | 31.991 | 10.008 | 10600 | 0.41 | 1.48 | 2750 | 1910 | 1.44 | 9230 |
| A4049 | A4138 | 12.680 | 34.988 | 10.998 | 12200 | 0.45 | 1.32 | 3160 | 2450 | 1.29 | 11500 |
| A4050 | A4138 | 12.700 | 34.988 | 10.998 | 12200 | 0.45 | 1.32 | 3160 | 2450 | 1.29 | 11500 |
| 00050 | 00150 | 12.700 | 38.100 | 13.495 | 19300 | 0.28 | 2.18 | 5010 | 2360 | 2.12 | 17100 |
| A4059 | A4138 | 14.987 | 34.988 | 10.998 | 12200 | 0.45 | 1.32 | 3160 | 2450 | 1.29 | 11500 |
| L21549 | L21511 | 15.875 | 34.988 | 10.998 | 14100 | 0.32 | 1.88 | 3650 | 1990 | 1.83 | 13900 |
| A6062 | A6157 | 15.875 | 39.992 | 12.014 | 12400 | 0.53 | 1.14 | 3220 | 2900 | 1.11 | 12300 |
| 03062 | 03162 | 15.875 | 41.275 | 14.288 | 22200 | 0.31 | 1.93 | 5770 | 3070 | 1.88 | 21300 |
| 11590 | 11520 | 15.875 | 42.862 | 14.288 | 17400 | 0.70 | 0.85 | 4510 | 5430 | 0.83 | 17400 |
| 17580 | 17520 | 15.875 | 42.862 | 16.670 | 29100 | 0.33 | 1.81 | 7550 | 4280 | 1.76 | 29200 |
| 05062 | 05185 | 15.875 | 47.000 | 14.381 | 24700 | 0.36 | 1.68 | 6420 | 3920 | 1.64 | 25400 |
| 09062 | 09195 | 15.875 | 49.225 | 19.845 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09062 | 09194 | 15.875 | 49.225 | 23.020 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 21063 | 21212 | 15.875 | 53.975 | 22.225 | 43000 | 0.59 | 1.02 | 11200 | 11300 | 0.99 | 42500 |
| HM81649 | HM81610 | 15.987 | 46.975 | 21.000 | 37100 | 0.55 | 1.10 | 9630 | 9000 | 1.07 | 39300 |
| A6067 | A6157A | 16.993 | 39.982 | 12.014 | 12400 | 0.53 | 1.14 | 3220 | 2900 | 1.11 | 12300 |
| A6067 | A6157 | 16.993 | 39.992 | 12.014 | 12400 | 0.53 | 1.14 | 3220 | 2900 | 1.11 | 12300 |
| 05066 | 05185 | 16.993 | 47.000 | 14.381 | 24700 | 0.36 | 1.68 | 6420 | 3920 | 1.64 | 25400 |
| A5069 | A5144 | 17.455 | 36.525 | 11.112 | 12100 | 0.49 | 1.23 | 3130 | 2610 | 1.20 | 11600 |
| LM11749 | LM11710 | 17.462 | 39.878 | 13.843 | 22900 | 0.29 | 2.10 | 5950 | 2910 | 2.04 | 23400 |
| 4C | 6 | 17.462 | 44.450 | 12.700 | 19900 | 0.48 | 1.25 | 5150 | 4220 | 1.22 | 20600 |
| 05068 | 05175 | 17.462 | 44.450 | 15.494 | 24700 | 0.36 | 1.68 | 6420 | 3920 | 1.64 | 25400 |
| 05070XS | 05185-S | 17.987 | 47.000 | 14.381 | 24700 | 0.36 | 1.68 | 6420 | 3920 | 1.64 | 25400 |
| 05070X | 05185-S | 18.000 | 47.000 | 14.381 | 24700 | 0.36 | 1.68 | 6420 | 3920 | 1.64 | 25400 |
| 1774 | 1729 | 19.004 | 56.896 | 19.368 | 42000 | 0.31 | 1.95 | 10900 | 5740 | 1.90 | 45300 |
| 1774 | 1729X | 19.004 | 56.896 | 19.368 | 42000 | 0.31 | 1.95 | 10900 | 5740 | 1.90 | 45300 |
| A6075 | A6157 | 19.050 | 39.992 | 12.014 | 12400 | 0.53 | 1.14 | 3220 | 2900 | 1.11 | 12300 |
| A6075 | A6162 | 19.050 | 41.275 | 11.905 | 12400 | 0.53 | 1.14 | 3220 | 2900 | 1.11 | 12300 |
| 4A | 6 | 19.050 | 44.450 | 12.700 | 19900 | 0.48 | 1.25 | 5150 | 4220 | 1.22 | 20600 |
| LM11949 | LM11910 | 19.050 | 45.237 | 15.494 | 30600 | 0.30 | 2.00 | 7930 | 4080 | 1.94 | 32000 |
| 05075 | 05185 | 19.050 | 47.000 | 14.381 | 24700 | 0.36 | 1.68 | 6420 | 3920 | 1.64 | 25400 |
| 05075X | 05185-S | 19.050 | 47.000 | 14.381 | 24700 | 0.36 | 1.68 | 6420 | 3920 | 1.64 | 25400 |
| 09067 | 09195 | 19.050 | 49.225 | 18.034 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09074 | 09195 | 19.050 | 49.225 | 19.845 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09078 | 09195 | 19.050 | 49.225 | 19.845 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09067 | 09194 | 19.050 | 49.225 | 21.209 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09067 | 09196 | 19.050 | 49.225 | 21.209 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09074 | 09194 | 19.050 | 49.225 | 23.020 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09074 | 09196 | 19.050 | 49.225 | 23.020 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09078 | 09194 | 19.050 | 49.225 | 23.020 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09078 | 09196 | 19.050 | 49.225 | 23.020 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09074 | 09201 | 19.050 | 50.800 | 20.638 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| LM11949 | LM11919 | 19.050 | 52.800 | 18.034 | 30600 | 0.30 | 2.00 | 7930 | 4080 | 1.94 | 32000 |
| 09067 | 09194-S | 19.050 | 52.883 | 18.430 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 09074 | 09194-S | 19.050 | 52.883 | 20.241 | 39700 | 0.27 | 2.26 | 10300 | 4680 | 2.20 | 40500 |
| 21075 | 21212 | 19.050 | 53.975 | 22.225 | 43000 | 0.59 | 1.02 | 11200 | 11300 | 0.99 | 42500 |
| 21075 | 21213 | 19.050 | 53.975 | 22.225 | 43000 | 0.59 | 1.02 | 11200 | 11300 | 0.99 | 42500 |
