叁件套外螺纹杆端轴承AM3、AM4、AM5、AM6、AM7、AM8、AM10、AM12、AM14、AM16、AM3L、AM4L、AM5L、AM6L、AM7L、AM8L、AM10L、AM12L、AM14L、AM16L
发布时间：2026-06-25
|
|
| Dimensions in inches |
| 型 号 |
B |
W |
H |
A |
D |
|
C |
M |
a |
Ultimate |
| |
Radial |
| Part Number |
Ball |
Ball |
Housing |
Centerline |
Head |
Ball |
Thread |
Thread |
Misalign |
Static Load |
| Right |
Left |
Bore |
Width |
Width |
Length |
Diameter |
Diameter |
Length |
Size |
Angle |
Capacity |
| Hand |
Hand |
+0.0015 |
+0.000 |
|
+0.010 |
+0.010 |
|
+0.062 |
UNF-3A |
Min |
Pounds |
| |
|
--0.0005 |
--0.005 |
|
--0.010 |
--0.010 |
|
--0.031 |
| AM3( T ) |
AM3L( T ) |
0.1900 |
0.312 |
0.250 |
1.250 |
0.625 |
0.437 |
0.750 |
10-32 |
13 |
2851 |
| AM4( T ) |
AM4L( T ) |
0.2500 |
0.375 |
0.281 |
1.562 |
0.750 |
0.500 |
1.000 |
1/4-28 |
16 |
5260 |
| AM5( T ) |
AM5L( T ) |
0.3125 |
0.437 |
0.344 |
1.875 |
0.875 |
0.625 |
1.250 |
5/16-24 |
14 |
7639 |
| AM6( T ) |
AM6L( T ) |
0.3750 |
0.500 |
0.406 |
1.938 |
1.000 |
0.719 |
1.250 |
3/8-24 |
12 |
9544 |
| AM7( T ) |
AM7L( T ) |
0.4375 |
0.562 |
0.437 |
2.125 |
1.125 |
0.812 |
1.375 |
7/16-20 |
14 |
10285 |
| AM8( T ) |
AM8L( T ) |
0.5000 |
0.625 |
0.500 |
2.438 |
1.312 |
0.937 |
1.500 |
1/2-20 |
12 |
16238 |
| AM10( T ) |
AM10L( T ) |
0.6250 |
0.750 |
0.562 |
2.625 |
1.500 |
1.125 |
1.625 |
5/8-18 |
16 |
17955 |
| AM12( T ) |
AM12L( T ) |
0.7500 |
0.875 |
0.687 |
2.875 |
1.750 |
1.312 |
1.750 |
3/4-16 |
14 |
28081 |
| AM14( T ) |
AM14L( T ) |
0.8750 |
0.875 |
0.765 |
3.375 |
2.000 |
1.375 |
2.000 |
7/8-14 |
17 |
45051 |
| AM16( T ) |
AM16L( T ) |
1.0000 |
1.375 |
1.000 |
4.125 |
2.750 |
1.875 |
2.125 |
1 1/4-12 |
17 |
76200 | | |
