滚珠丝杠轴承BS1547TN1、BS1747TN1、BS2047TN1、BS2562TN1、BS3062TN1、BS3072TN1、BS3572TN1、BS4072TN1、BS4090TN1、BS4575TN1、BS45100TN1、BS50100TN1、BS5590TN1、BS55100TN1、BS55120TN1、BS60120TN1、BS75110TN1、BS100150TN1

发布时间：2026-06-25

轴承代号	外形尺寸					额定载荷		极限转速		重量
	d	D	B	rsmin	a	Cr	Cor	脂油		≈
	mm				≈	KN		r/min		kg
BS1547TN1	15	47	15	1	35	21.5	27	12000	17000	0.14
BS1747TN1	17	47	15	1	35	21.5	27	125000	17000	0.14
BS2047TN1	20	47	15	1	37	19.3	25	12000	17000	0.13
BS2562TN1	25	62	15	1	46	28.5	41.5	9000	13000	0.24
BS3062TN1	30	62	15	1	48	26	39	9000	13000	0.23
BS3072TN1	30	72	15	1	52	31	54	8000	11000	0.35
BS3572TN1	35	72	15	1	54	30	50	8000	11000	0.3
BS4072TN1	40	72	15	1	56	28	49	8000	11000	0.26
BS4090TN1	40	90	20	1.5	67	50	83	6300	8500	0.65
BS4575TN1	45	75	15	1	60	28.5	52	7500	10000	0.26
BS45100TN1	45	100	20	1.5	74	58.5	104	5600	7500	0.81
BS50100TN1	50	100	20	1.5	76	58.5	104	5600	7500	0.75
BS5590TN1	55	90	15	1	70	32.5	65.6	6300	8500	0.38
BS55100TN1	55	100	20	1.5	77	40.5	81.5	6000	8000	0.75
BS55120TN1	55	120	20	1.5	86	60	116	5000	6700	1.18
BS60120TN1	60	120	20	1.5	88	61	120	4800	6300	1.11
BS75110TN1	75	110	15	1.5	88	35.5	83	5000	6700	0.75
BS100150TN1	100	150	22.5	2	120	69.5	173	3800	5000	1.37
