Dimensions (inch) | d | 2.4375 | ![]() |
F | 2.1250 | ||
A | 13.7500 | ||
C | 3.8750 | ||
E | 11.0000 | ||
H | 4.0000 | ||
H1 | 7.8125 | ||
Approx. Wgt. lbs | 40.000 | ||
Triple Seals Req'd / Seal No. (a) | LER-37 | ||
Triple Seals Req'd / Seal Qty. (a) | 2 | ||
Additional Seals / Seal No. | TER-37 V | ||
Additional Seals / Seal Qty. | 2 | ||
Stabilizing Rings Req'd / No. | SR-1615 | ||
Stabilizing Rings Req'd / Qty. | 2 | ||
Appropriate End Plug | EPR-7 | ||
Suitable Adapter | H-315x2 7/16 | ||
Suitable for Bearings | 1315-K | ||
Interchange | FAG | SAF 615 | |
SKF | SAF 615 | ||
Torrington | SAF 615 | ||
* Also available in four-bolt base. Use "FSAF" prefix. Example: FSAF-617 1) The above are split cast iron housings. For cast steel housings use "SAFS" prefix. Example: SAFS-617. 2) Sizes SAF-618 and larger are all four-bolt base units. 3) Taconite seals ( TER-..V ) can be used in place of the standard LER seal. Example: TER-17V replaces LER-17 4) Parts may not be interchangeable with parts from other manufacturers. |
