Dimensions (metric) | d | 75 | |
b | 110 | ||
E | 320 | ||
A | 380 | ||
L | 155 | ||
H | 112 | ||
H1 | 218 | ||
Housing Only Approx. Wgt.lbs | 33.100 | ||
Additional Seals / Seal No. | SN-17-TA | ||
Additional Seals / Seal Qty. | 2 | ||
Stabilizing Rings Req'd / No. | SR 1617 | ||
Stabilizing Rings Req'd / Qty. | 2 | ||
Suitable Adapter | H-317x75mm. | ||
Suitable for Bearings | 20317-K | ||
Interchange | FAG | SN 617 | |
SKF | SN 617 | ||
STEYR | SN 617 | ||
1) The above are cast-iron split housings and are equipped with felt seals. 2) Felt seals can be substituted with SN-.. TA rubber seals. These seals are not interchangeable with housings from other manufacturers. Consult factory for availability. 3) The above series has two bolt bases and two bolt caps. |
