搜轴承 -- SKF轴承型号查询 -- 轴承单元 -- SKF FYC 50 TF轴承

d - 50 mm

A - 39.5 mm

A₁ - 14 mm

A₃ - 12 mm

B - 51.6 mm

B₄ - 9 mm

D_a - h8 - 110 mm

D_b - 113.1 mm

J - 138 mm

J₁ - 97.6 mm

L - 165 mm

H - 16 mm

s₁ - 32.6 mm

T - 42.6 mm

D_N - 6.5 mm

SW_N - 7 mm

G_N - 1/4-28 SAE-LT

R_G - 1/4-28 UNF

R₁ - 22 mm

Basic dynamic load rating - C - 35.1 kN

Basic static load rating - C₀ - 23.2 kN

Fatigue load limit - P_u - 0.98 kN

Limiting speed with shaft tolerance h6 - 4000 r/min

Weight - 2.85 kg

Thread - G₂ - M10x1

Hexagonal key size for grub screw - H - 5 mm

Recommended tightening torque for grub screw - 16.5 N·m

• SKF FYC50TF轴承单元图纸和参数

• 发布时间：2025-06-16
• 产品型号: FYC50TF
• 新型号:FYC 50 TF
• 内径：50mm 外径：39,5mm 厚度：14mm
• 主要类别：轴承单元
• 应用行业:车轮车床,化工,塑料吹塑,气动连接件,焊接设备,龙门加工,磁性元器,塔吊,登高梯,橡胶制品机械设备,医用服饰
• 近似型号:INA RASEY50-JIS INA LCJT50-N INA PASEY50-N FYH UCP216-50 INA PCJT50-N-FA125 KOYO UCTH201-8-150 KOYO UCTH204-12-150 SKF SYNT 50 L KOYO UCTU314-500 INA RCJY50-N
• 天津八零动力国际贸易有限公司专业经销 FYC 50 TF产品，常年备货SKF FYC 50 TF 轴承单元. 我们可以可以快速将您所需要的FYC 50 TF产品运送到全球任意地方购买 SKF FYC 50 TF 我认准八零动力工业，价格低，品种全，交货快，质量有保证！ 轴承单元订购电话022-58519723/22/21
