搜轴承 -- SKF轴承型号查询 -- 轴承单元 -- SKF FYTJ 40 TF轴承

d - 40 mm

A - 36 mm

A₁ - 16 mm

A₃ - H14 - 3.2 mm

B - 49.2 mm

B₄ - 8 mm

D_a - H11 - 88.9 mm

D_b1 - 97 mm

D_b2 - 100 mm

J - 144 mm

H - 175 mm

L - 100 mm

H - 16 mm

s₁ - 30.2 mm

T - 51.2 mm

J₆ - 116 mm

J₇ - 16 mm

N₄ - 2 mm

D_N - 6.5 mm

SW_N - 7 mm

G_N - 1/4-28 SAE-LT

R_G - 1/4-28 UNF

R₁ - 21.5 mm

R_α - 45 °

Basic dynamic load rating - C - 30.7 kN

Basic static load rating - C₀ - 19 kN

Fatigue load limit - P_u - 0.8 kN

Limiting speed - 4800 r/min

Mass bearing unit - 1.5 kg

Thread - G₂ - M8x1

Hexagonal key size for grub screw - H - 4 mm

Recommended tightening torque for grub screw - 6.5 N·m

• SKF FYTJ40TF轴承单元图纸和参数

• 发布时间：2025-05-02
• 产品型号: FYTJ40TF
• 新型号:FYTJ 40 TF
• 内径：40mm 外径：36mm 厚度：16mm
• 主要类别：轴承单元
• 应用行业:合页行业,电动泵等,吊钩,真空系统,激光切割,涂料油漆,其他车床,油桶搬运,吸液嘴类,吸盘行业,仓储货架设备
• 近似型号:INA PASEY40-N SKF TUWK 40 LTHR SKF PFD 40 TF FYH UCIP213-40 FYH UCFC213-40 NKE RME40-N SKF FYTJ 40 TF INA RSHEY40-N INA TCJ40-N INA RASEY40-N
• 天津八零动力国际贸易有限公司专业经销 FYTJ 40 TF产品，常年备货SKF FYTJ 40 TF 轴承单元. 我们可以可以快速将您所需要的FYTJ 40 TF产品运送到全球任意地方购买 SKF FYTJ 40 TF 我认准八零动力工业，价格低，品种全，交货快，质量有保证！ 轴承单元订购电话022-58519723/22/21
