CKA100X31.5-45单向轴承、CKA105X35-30单向轴承、CKA105X34-35单向轴承、CKA105X35-35单向轴承、CKA110X34-30单向轴承、CKA110X34-35单向轴承、CKA110X34-38单向轴承、CKA110X34-40单向轴承、CKA125X38-50单向轴承、CKA130X52-38单向轴承、CKA130X55-40单向轴承、CKA130X38-45单向轴承、CKA130X38-50单向轴承、CKA135X38-60单向轴承 — 搜轴承黑板报
搜轴承 -- 黑板报 -- CKA100X31.5-45单向轴承、CKA105X35-30单向轴承、CKA105X34-35...

CKA100X31.5-45单向轴承、CKA105X35-30单向轴承、CKA105X34-35单向轴承、CKA105X35-35单向轴承、CKA110X34-30单向轴承、CKA110X34-35单向轴承、CKA110X34-38单向轴承、CKA110X34-40单向轴承、CKA125X38-50单向轴承、CKA130X52-38单向轴承、CKA130X55-40单向轴承、CKA130X38-45单向轴承、CKA130X38-50单向轴承、CKA135X38-60单向轴承

发布时间：2025-05-04

型 号 公称转矩Tn(N·m) 超越时的限转速n(r/min) 外 环 内 环  质量 (kg)
D (h7) 键槽(b×t) L  d (H7) 键槽 (b×t) L1
CKA50×24-10 31.5 2500 50 3×1.8 22 10 3×1.4 24 0.24
CKA50×24-12 31.5 2500 50 3×1.8 22 12 3×1.4 24 0.24
CKA52×24-16 31.5 2250 52 5×1.9 22 16 3×1.4 24 0.27
CKA55×24-18 50 2250 55 4×2.5 22 18 4×1.8 24 0.28
CKA60×22-19 63 2000 60 6×3.5 22 19 6×2.8 22 0.3
CKA60×24-20 63 2000 60 6×3.5 22 20 6×2.8 24 0.33
CKA63×26-24 100 1800 63 6×3.5 24 24 6×2.8 24 0.37
CKA63×26-25 100 1800 63 6×3.5 24 25 6×2.8 26 0.37
CKA63×32-25 140 1800 63 6×3.5 30 25 6×2.8 32 0.48
CKA65×26-24 100 1800 65 6×3.5 24 24 6×2.8 26 0.38
CKA70×32-12 150 1500 70 8×4.0 30 12 3×1.4 32 0.67
CKA70×24-20 150 1500 70 6×3.5 22 20 6×2.8 24 0.62
CKA70×32-25 150 1500 70 8×4.0 30 25 8×3.3 32 0.63
CKA70×32-28 180 1500 70 8×4.0 30 28 8×3.3 32 0.6
CKA72×27-25 180 1500 72 6×3.5 L=14 20 25 8×3.3 27 0.54
CKA75×40-25 180 1500 75 8×4.0 30 25 8×3.3 40 0.79
CKA80×32-22 200 1500 80 8×4.0 30 22 6×2.8 32 1.29
CKA80×32-25 200 1500 80 8×4.0 32 25 8×3.3 32 0.9
CKA80×26-30 200 1500 80 8×4.0 26 30 8×3.3 26 0.73
CKA80×32-30 200 1500 80 8×4.0 30 30 8×3.3 32 0.87
CKA80×31-35 200 1500 80 12×4 31 35 10×2.5 31 0.75
CKA85×28-30 200 1500 85  5×3.0  L=14 20 30 8×3.3 28 0.83
CKA90×37-25 200 1500 90 8×4.0 37 25 8×3.3 37 1
CKA100×34-28 315 1250 100 10×5 32 28 8×4.3 34 1.15
CKA100×34-32 315 1250 100 10×5 32 32 10×3.3 34 1.25
CKA100×34-35 315 1250 100 10×5 32 35 10×3.3 34 1.34
CKA100×34-38 315 1250 100 10×5 32 38 10×3.3 34 1.28
CKA100×34-40 315 1250 100  10×5   L=28 32 40 10×3.3 34 1.2
CKA100×67-40 315 1250 100  8×4.0  L=20 25 40 10×3.6 67 1.46
CKA100×31.5-45 315 1250 100 2-8×4 31.5 45 8×3.3 31.5 1.54
CKA105×35-30 315 1250 105 10×5   L=16 20 30 8×3.3 35 1.55
CKA105×34-35 315 1250 105  10×5   L=26 32 35 10×3.3 34 1.55
CKA105×35-35 315 1250 105 6×3.5 25 35 8×3.3 35 1.56
CKA110×34-30 400 1000 110 10×5 32 30 8×3.3 34 1.82
CKA110×34-35 400 1000 110 10×5 32 35 10×3.3 34 1.82
CKA110×34-38 400 1000 110 10×5 32 38 10×3.3 34 1.67
CKA110×34-40 400 1000 110 10×5 32 40 10×3.3 34 1.91
CKA125×38-50 500 800 125 14×5.5 36 50 14×3.8 38 2.21
CKA130×52-38 500 800 130 12×5.0 50 38 12×3.3 52 3.14
CKA130×55-40 500 800 130 8×4.0 35 40 12×3.3 55 2.62
CKA130×38-45 500 800 130 14×5.5 36 45 14×3.8 38 4.31
CKA130×38-50 500 800 130 14×5.5 36 50 14×3.8 38 3.02
CKA135×38-60 600 800 135 14×5.5 36 60 18×4.4 38 2.65
CKA136×52-35 800 800 136 8-φ9 50 35 10×3.3 52 4.5
CKA136×52-45 800 800 136 6-M8 52 45 14×3.8 52 4.32
CKA140×55-50 1250 800 140 16×6.0 53 50 16×4.3 55 5.1
CKA140×38-60 1000 800 140 14×5.5 36 60 14×3.0 38 2.74
CKA145×34-45 1000 800 145 6-M10 34 45 12×3.8 34 3.35
CKA160×75-50 1500 800 160 6-M8 72 50 14×3.8 75 7.08
CKA160×55-55 2000 800 160 18×7.0 53 55 16×4.3 55 6.96
CKA160×35-70 1500 800 160 10×5.0 35 70 8×3.3 35 3.46
CKA170×55-60 2240 800 170 18×7.0 52 60 18×4.4 55 7.8
CKA170×55-65 2240 800 170 18×7.0 52 65 18×4.4 55 7.61
CKA180×52-65 2000 800 180 6-M8 52 65 18×4.4 52 7.35
CKA180×55-65 2500 800 180 18×7.0 52 65 18×4.4 55 8.69
CKA190×38-85 2500 800 190 14×5.0 36 85 14×3.8 38 5.5
CKA200×55-65 2800 800 200 20×7.5 53 65 20×3.9 55 11.02
CKA210×88-50 4000 800 210 6-M10 85 50 14×3.8 88 18.52
CKA210×85-75 4000 800 210 6-φ13 70 75 20×4.9 70 14.25
CKA215×70-75 4500 600 215 6-M12 70 75 20×4.4 70 15
