KG040AR0薄壁角接触球轴承、KG042AR0薄壁角接触球轴承、KG045AR0薄壁角接触球轴承、KG047AR0薄壁角接触球轴承、KG050AR0薄壁角接触球轴承、KG055AR0薄壁角接触球轴承、KG060AR0薄壁角接触球轴承、KG065AR0薄壁角接触球轴承、KG070AR0薄壁角接触球轴承
发布时间：2019-10-15
|
轴承型号 |
英制尺寸 |
尺寸毫米 |
宽度 |
基本载荷 |
重量 | ||||||
|
内径 |
外径 |
内径 |
外径 |
径向 |
轴向 | ||||||
|
d |
D |
d |
D |
mm |
Cor |
Cr |
Coa |
Ca |
Kg | ||
|
KLGA040 |
KG040AR0 |
4 |
6 |
101.6 |
152.4 |
25.4 |
42140 |
20980 |
121620 |
60590 |
1.64 |
|
KLGA042 |
KG042AR0 |
4.25 |
6.25 |
107.95 |
158.75 |
25.4 |
44230 |
21690 |
127710 |
62630 |
1.74 |
|
KLGA045 |
KG045AR0 |
4.5 |
6.5 |
114.3 |
165.1 |
25.4 |
46360 |
22360 |
133800 |
64590 |
1.79 |
|
KLGA047 |
KG047AR0 |
4.75 |
6.75 |
120.65 |
171.45 |
25.4 |
48450 |
23030 |
139840 |
66540 |
1.89 |
|
KLGA050 |
KG050AR0 |
5 |
7 |
127 |
177.8 |
25.4 |
50540 |
23690 |
145930 |
68450 |
2 |
|
KLGA055 |
KG055AR0 |
5.5 |
7.5 |
139.7 |
190.5 |
25.4 |
54760 |
25030 |
158110 |
72190 |
2.15 |
|
KLGA060 |
KG060AR0 |
6 |
8 |
152.4 |
203.2 |
25.4 |
58990 |
26270 |
170240 |
75830 |
2.3 |
|
KLGA065 |
KG065AR0 |
6.5 |
8.5 |
165.1 |
215.9 |
25.4 |
63210 |
27520 |
182420 |
79430 |
2.45 |
|
KLGA070 |
KG070AR0 |
7 |
9 |
177.8 |
228.6 |
25.4 |
67390 |
28720 |
194600 |
82900 |
2.66 |
|
KLGA075 |
KG075AR0 |
7.5 |
9.5 |
190.5 |
241.3 |
25.4 |
71610 |
29920 |
206740 |
86320 |
2.81 |
|
KLGA080 |
KG080AR0 |
8 |
10 |
203.2 |
254 |
25.4 |
75830 |
31070 |
218920 |
89700 |
2.97 |
|
KLGA090 |
KG090AR0 |
9 |
11 |
228.6 |
279.4 |
25.4 |
84280 |
33340 |
243230 |
96190 |
3.27 |
|
KLGA100 |
KG100AR0 |
10 |
12 |
254 |
304.8 |
25.4 |
92680 |
35520 |
267550 |
102500 |
3.63 |
|
KLGA110 |
KG110AR0 |
11 |
13 |
279.4 |
330.2 |
25.4 |
101120 |
37650 |
291860 |
108640 |
3.94 |
|
KLGA120 |
KG120AR0 |
12 |
14 |
304.8 |
355.6 |
25.4 |
109530 |
39690 |
316220 |
114590 |
4.3 |
|
KLGA140 |
KG140AR0 |
14 |
16 |
355.6 |
406.4 |
25.4 |
126370 |
43650 |
364850 |
126060 |
4.94 |
|
KLGA160 |
KG160AR0 |
16 |
18 |
406.4 |
457.2 |
25.4 |
143220 |
47470 |
413470 |
137040 |
5.62 |
|
KLGA180 |
KG180AR0 |
18 |
20 |
457.2 |
508 |
25.4 |
160110 |
51120 |
462280 |
147570 |
6.26 |
|
KLGA200 |
KC200AR0 |
20 |
22 |
508 |
558.8 |
25.4 |
176960 |
54670 |
510730 |
157750 |
6.89 |
