HR15E杆端轴承、HR16E杆端轴承、HR17E杆端轴承、HR18E杆端轴承、HR20E杆端轴承
发布时间：2025-05-03
Dimensions in mm
|
MINEBEA |
øB H7 |
øD ±0.5 |
W 0 －0.13 |
H ±0.13 |
F ±0.5 |
TH JIS CL2 |
L ±0.7 |
α DEG |
øO (REF) |
SøDB (REF) |
|---|---|---|---|---|---|---|---|---|---|---|
|
HR3E |
3 |
16.0 |
7.0 |
5.25 |
30.0 |
M3×0.5 |
10.0 |
18 |
5.2 |
8.73 |
|
HR4E |
4 |
18.0 |
9.5 |
7.75 |
35.0 |
M4×0.7 |
16.0 |
16 |
5.8 |
11.11 |
|
HR5E |
5 |
20.5 |
11.0 |
8.75 |
39.5 |
M5×0.8 |
22.0 |
15 |
7.8 |
13.49 |
|
HR6E |
6 |
M6×1.0 | ||||||||
|
HR8E |
8 |
23.0 |
8.25 |
46.0 |
M8×1.25 |
29.0 |
14 |
10.9 |
15.48 | |
|
HR10E |
10 |
26.0 |
12.5 |
10.75 |
47.0 |
M10×1.5 |
8 |
12.2 |
17.46 | |
|
HR12E |
12 |
34.0 |
16.0 |
13.25 |
62.0 |
M12×1.75 |
37.0 |
10 |
15.4 |
22.22 |
|
HR14E |
14 |
36.0 |
17.0 |
14.25 |
64.0 |
M14×2.0 |
38.0 |
8 |
18.9 |
25.40 |
|
HR15E |
15 |
38.0 |
18.0 |
65.0 |
11 |
19.0 |
26.19 | |||
|
HR16E |
16 |
39.0 |
19.0 |
15.25 |
66.5 |
M16×2.0 |
39.5 |
10 |
19.2 |
26.99 |
|
HR17E |
17 |
41.0 |
20.0 |
72.5 |
M16×1.5 |
42.0 |
12 |
20.4 |
28.58 | |
|
HR18E |
18 |
43.0 |
16.30 |
79.5 |
M18×1.5 |
46.0 |
10 | |||
|
HR20E |
20 |
45.0 |
22.0 |
83.0 |
M20×1.5 |
50.0 |
13 |
22.9 |
31.75 | |
|
HR22E |
22 |
52.0 |
19.30 |
86.0 |
M22×1.5 |
51.0 |
6 |
27.1 |
34.92 | |
|
HR25E |
25 |
70.0 |
35.0 |
25.30 |
105.0 |
M24×2.0 |
59.0 |
15 |
32.3 |
47.62 |
|
HR28E |
28 |
75.0 |
110.0 |
M27×2.0 |
62.0 |
14 |
36.8 |
50.80 | ||
|
HR30E |
30 |
78.0 |
37.0 |
26.30 |
120.0 |
M30×2.0 |
65.0 |
40.4 |
54.77 |
Dimensions in mm
|
MINEBEA |
Static Limit load kN |
Static Ultimate Load kN |
Fatigue Load*2 kN |
Approx. Weight g |
|
|---|---|---|---|---|---|
| Radial | Axial*1 | ||||
|
HR3E |
3.62 |
2.94 |
4.51 |
0.73 |
25 |
|
HR4E |
6.27 |
3.53 |
7.84 |
1.27 |
30 |
|
HR5E |
10.29 |
5.09 |
12.84 |
2.10 |
35 |
|
HR6E |
14.51 |
18.14 |
2.99 | ||
|
HR8E |
26.77 |
5.58 |
33.44 |
5.54 |
40 |
|
HR10E |
37.65 |
6.76 |
47.07 |
7.84 |
65 |
|
HR12E |
62.46 |
8.33 |
78.06 |
12.94 |
126 |
|
HR14E |
82.96 |
9.02 |
103.65 |
17.25 |
140 |
|
HR15E |
85.90 |
9.31 |
107.38 |
17.84 |
165 |
|
HR16E |
100.71 |
9.70 |
125.81 |
20.98 |
195 |
|
HR17E |
101.40 |
10.29 |
126.70 |
21.08 |
220 |
|
HR18E |
120.62 |
12.16 |
150.72 |
25.10 |
250 |
|
HR20E |
121.30 |
12.84 |
151.61 |
25.20 |
290 |
|
HR22E |
156.21 |
15.10 |
195.25 |
32.55 |
450 |
|
HR25E |
300.08 |
20.88 |
375.10 |
62.56 |
1150 |
|
HR28E |
283.70 |
23.24 |
354.60 |
59.13 |
1500 |
|
HR30E |
271.93 |
24.81 |
339.89 |
56.68 |
1800 |
